Resilient Distributed Dataset(RDD)

데먕 2019. 9. 8. 22:32

1. Overview

Resilient Distributed Datasets (RDD) is a fundamental data structure of Spark. It is an immutable distributed collection of objects. Each dataset in RDD is divided into logical partitions, which may be computed on different nodes of the cluster. RDDs can contain any type of Python, Java, or Scala objects, including user-defined classes.

There are two ways to create RDDs − parallelizing an existing collection in your driver program or referencing a dataset in an external storage system, such as a shared file system, HDFS, HBase, or any data source offering a Hadoop Input Format.

Spark makes use of the concept of RDD to achieve faster and efficient MapReduce operations.

2. Description

2.1 Keyword of RDDs

Feature	Description
Resilient	fault-tolerant with the help of RDD lineage graph and so able to recompute missing or damaged partitions due to node failures
Distributed	Data residing on multiple nodes in a cluster
Dataset	A collection of partitioned data with primitive values or values of values, e.g. tuples or other objects that represent records of the data you work with

2.2 Traits

Traits	Description
In-Memory	The data inside RDD is stored in memory as much size and long time as possible
Immutable(Read-only)	Not change once created and can only be transformed using transformations to new RDDs
Lazy evaluated	The data inside RDD is not available or transformed until an action is executed that triggers the execution
Cacheable	Being able to hold all the data in persistent storage like memory which default and most preferred or disk the least preferred due to access speed
Parallel	process data in parallel
Typed	RDD records have types, e.g. Long in RDD[long] or (Int, String) in RDD[(Int, String)]
Partitioned	Records are partitioned split into logical partitions and distributed across nodes in a cluster
Location-Stickiness	RDD can define placement preferences to compute partitions as close to the records as possible

2.3 Terminology

Terminology	Description
Partitions	The units of parallelism Each partition comprised of records Being able to control the number of partitions of an RDD using repartition or coalesce transformations.
Transformations	Lazy operations that return another RDD
Actions	Operations that trigger computation and return values
Data locality	Spark tries to be as close to data as possible without wasting time to send data across a network by means of RDD shuffling
RDD shuffling	Process of redistributing data across partitions(aka repartitioning) that may or may not cause moving data across JVM processes or even over the wire Leverage partial aggregation to reduce data transfer
Intermediate result	Reused intermediate in-memory results across multiple data-intensive workloads with no need for copying large amounts of data over the network

2.4 Contract

Contract	Description
Parent RDDs	RDD dependencies
An array of partitions	a dataset is divided to
A compute function	Doing a computation on partitions
Optional preferred locations	aka locality info. hosts for a partition where the records live or are the closest to read from

2.5 Representing RDDs

Features	Description
Partition	Represent atomic pieces of the dataset
Dependencies	List of dependencies that an RDD has on its parent RDDs or data sources Narrow Dependencies: Where each partition of the parent node is used by at most one child partition. For example, map and filter operations Wide Dependencies: Where multiple child partitions user a single parent partition.
Iterator	a function that computes an RDD based on its parents
partitioner	Whether data is range/hash partitioned
preferredLocation	Nodes where a partition can be accessed faster due to data locality

2.6 Transformation

A lazy operation on an RDD that returns another RDD, like map, flatMap, filter, reduceBy, join, cogroup, etc.

2.7 Types of RDDs

name	Description
ParallelCollectionRDD	A collection of elements with numSlices partitions and optional location press The result of SparkContext.parallelize and SparkContext.makeRDD methods The data collection is split on the numSlices slices.
CoGroupedRDD	An RDD that cogroups its pair RDD parents For each key k in parent RDDs, the resulting RDD contains a tuple with the list of values for that key
HadoopRDD	An RDD that provides core functionality for reading data stored in HDFS using the older MapReduce API The most notable use case is the return RDD of SparkContext.textFile
MapPartitionsRDD	A result of calling operations like map, flatMap, filter, mapPartitions, etc.
CoalescedRDD	A result of repartition or coalesce transformations Coalesce Transformation can trigger RDD shuffling depending on the shuffle flag
ShuffledRDD	A result of shuffling, e.g. after repartition or coalesce transformations
PipedRDD	An RDD created by piping elements to a forked external process
PairRDD	(implicit conversion by PairRDDFunctions) An RDD of key-value pairs that a result of groupByKey and join operations
DoubleRDD	(implicit conversion as org.apache.spark.rdd.DoubleRDDFunctions) that is an RDD of Double type
SequenceFileRDD	(implicit conversion as org.apache.spark.rdd.SequenceFileRDDFunctions) that is an RDD that can be saved as a SequenceFile

3. Example

3.1 Creating RDDs

3.1.1 SparkContext.parallelize

Mainly used to learn Spark in the Spark shell
Requires all the data to be available on a single machine

scala> val rdd = sc.parallelize(1 to 1000)
rdd: org.apache.spark.rdd.RDD[Int] = ParallelCollectionRDD[0] at parallelize at <console>:25

scala> val data = Seq.fill(10)(util.Random.nextInt)
data: Seq[Int] = List(-964985204, 1662791, -1820544313, -383666422, -111039198, 310967683, 1114081267, 1244509086, 1797452433, 124035586)

scala> val rdd = sc.parallelize(data)
rdd: org.apache.spark.rdd.RDD[Int] = ParallelCollectionRDD[0] at parallelize at <console>:29

3.1.2 SparkContext.textFile

Creating RDD from reading files

scala> val words = sc.textFile("README.md").flatMap(_.split("\\W+")).cache
words: org.apache.spark.rdd.RDD[String] = MapPartitionsRDD[27] at flatMap at <console>:24
