Sigmoid and Softmax
1. Softmax
Softmax function calculates the probability distribution of the event over k different events. This function will calculate the probabilities of each target class over all possible target classes.
Equation
$$P(y=j | x) = \frac{e^{x_j}}{\sum_{k=1}^K e^{x_k}}$$
Plot
x = np.arange(-2.0, 6.0, 0.1)
input = np.vstack([x, np.ones_like(x), 0.2 * np.ones_like(x)])
Characteristic
- It normalizes your data: Outputs a proper probability distribution
- It is differentiable
- A hardmax function such as argmax is not differentiable. The softmax gives at least a minimal amount of probability to all elements in the output vector, and so is nicely differentiable, hence the term “soft” in softmax
- It uses the exponential form. The interesting property of the exponential function combined with the normalization in the softmax is that high scores in x become much more probable than low scores
2. Sigmoid
Equation
$$sigmoid(x_{i})=\sigma(x)=\frac{1}{1+e^{-x_{i}}}$$
Plot
Characteristic
Input domain: $(-\infty, +\infty )$
Output range: (0, +1)
$\sigma(0)=0.5$
The function is monotonically increasing
The function is continuous everywhere
The function is differentiable everywhere in its domain
Numerically, it is enough to compute this function’s value over a small range of numbers, e.g., [-10, +10]. For values less than -10, the function’s value is almost zero. For values greater than 10, the function’s values are almost one
